FDM PROCESS

Continous extrusion of thermoplastic filament.

Materials: Additional Services

SLA PROCESS

Photochemical laser linking of thermoset polymer resin.

CARBON FIBER REINFORCED NYLON

This material is ideal for applications that require a structural component with high modulus, improved chemical and thermal resistance, superior dimensional stability and excellent surface quality.

Low Gloss Matte Black
Component embedment
100, 125, 200µm Layer Heights
Max Build Size: 320 x 132 x 154mm

GLASS FILLED REINFORCED NYLON

Glass filled parts have very little flex, and they retain their dimensional accuracy better than nylon alone. Excellent for creating parts that need to stand up to a beating or need to absorb large amounts of kinetic energy. Under repeated shock, glass-fiber reinforced nylon prints maintain their shape and structural integrity.

Low Gloss
Available in Matte Black, White, Silver, Safety Orange, Red, Olive Green, Blue, and Desert Tan
100, 125, 200µm Layer Heights
Max Build Size: 320 x 132 x 154mm

NYLON (PA6)

Toughest among all engineering plastics. Build fixtures, guides, jigs, guards and other manufacturing aids that require good mechanical and tensile strength. Excellent resistance to heat, oils, solvents and chemicals.

Cost Effective
Available in Black, Natural, Red, Green, and Blue
100, 125, 200µm Layer Heights
Max Build Size: 320 x 132 x 154mm

CARBON FIBER REINFORCED PETG

Made in the USA using premium PETG and High-Modulus Carbon Fiber. This material is ideal for structural components with high modulus, excellent surface quality, dimensional stability, light weight and low cost.

Low Gloss Matte Black
100, 125, 200µm Layer Heights
Max Build Size: 320 x 132 x 154mm

LOW GLOSS PETG

Standard PETG but with a low gloss that helps hide the layer lines to offer a more technical look. Features superior chemical resistance, low moisture absorption, low shrink, and low warpage when compared to ABS. Perfect for applications that require the performance of PETG but with a more sophisticated fit and finish.

Low Gloss
Available in Military Tactical Colors Matte Black, Arctic White Light Sand, Flat Dark Earth, Battleship Grey, Graphite, and Blaze Orange
100, 125, 200, 250, 330µm Layer Heights
Large Build Size: 254 x 254 x 305mm

PETG

The modern alternative to ABS. PETG outperforms ABS in nearly every aspect but is much less prone to shrink and warping in additive processes. PETG is our most cost effective material and is recommended for many appreciations due to its good mechanical strength and aesthetic characteristics. It is often used for applications which need to contain food and water.

FDA approved, food safe
Available in Black, Gray, Natural, White and Vibrant Translucents: Blue, Green, Orange, Purple, Red, and Yellow
100, 125, 200, 250, 330µm Layer Heights
Large Build Size: 254 x 254 x 305mm

POLYCARBONATE ASA

ASA is a highly UV-resistant weatherable polymer. PC/ASA's UV-stability makes it an ideal material for outdoor applications that will experience intense exposure to the sun and weather. Commonly used in the Auto, Marine, and RV industries for exterior applications such as mirror housings, cowl covers, radiator grills, and sensor housings.

Available in White and Grey
250, 330µm Layer Heights
Large Build Size: 254 x 254 x 305mm

POLYCARBONATE ABS

PC/ABS alloys the mechanical properties & high-heat resistance of PC with the printability of ABS and allows for the printing of functional prototypes and production parts with very fine detail and excellent surface quality.

Available in Black and White
250, 330µm Layer Heights
Large Build Size: 254 x 254 x 305mm

ABS

Economy grade material that is strong and ductile. Commonly used for prototyping in areas where heat tolerance and wear resistance is needed.

Available in Black, White, Natural, Arctic Blue, Ultra Blue, Alpine Green, Yellow, Orange, Red, Burgundy, Light Grey, Dark Grey and Metallic's: Copper, Silver and Gold
250, 330µm Layer Heights
Large Build Size: 254 x 254 x 305mm

Materials: Services

GREY PRO RESIN

Grey Pro Resin offers high precision, moderate elongation, and low creep. This material is great for concept modeling and functional prototyping, especially for parts that will be handled repeatedly.

Available in light grey.
Supports resolutions of 100 and 50 microns.

RECOMMENDED FOR:

Form and fit testing
Injection molded product prototypes
Mold masters for plastics, silicones, and more
Jigs and fixtures for manufacturing

NOT RECOMMENDED FOR:

High impact applications

RIGID RESIN (GLASS FILLED)

Rigid Resin is reinforced with glass to offer very high stiffness and a polished finish. This material is highly resistant to deformation over time and is great for printing thin walls and features.

Available in ceramic white. Other pigments available per request.
Supports resolutions of 100 and 50 microns.

RECOMMENDED FOR:

Thin walls and features
Turbines and fan blades
Jigs, fixtures, and tools
Manifolds
Electrical casings and automotive housings

NOT RECOMMENDED FOR:

Parts that must bend
Low-friction surfaces
Drop or impact testing

DURABLE RESIN

With low modulus, high elongation, and high impact strength, Durable Resin produces parts with a smooth, glossy finish and high resistance to deformation. Use this material for applications requiring minimal friction.

Available in opaque white. Other pigments available per request.
Supports resolutions of 100 and 50 microns.

RECOMMENDED FOR:

Parts requiring high impact strength
Prototyping parts that will be made out of polypropylene or HDPE
Parts that require a low-friction surface, like ball joints
Parts that are both rigid and flexible
Snap-fit parts and flexures

NOT SUITABLE FOR:

Parts with very fine details
Parts that will be used in elevated temperature environments
Constant loading

TOUGH RESIN

Tough Resin balances strength and compliance, making it the ideal choice for prototyping strong, functional parts and assemblies that will undergo brief periods of stress or strain.

Available in transparent blue and graphite.
Supports resolutions of 100 and 50 microns.

RECOMMENDED FOR:

High-stress components
Snap-fit functions and living hinges
Post Machining
Cyclic loading
Works-like/feels like ABS prototyping
Geometrically accurate prototyping under load

NOT RECOMMENDED FOR:

Very fine features or thin walls
Rigid or stiff prints
High-temperature applications
Constant loading

ELASTIC RESIN

Our softest Engineering Resin, this 50A Shore durometer material is suitable for prototyping parts normally produced with silicone. Choose Elastic Resin for parts that will bend, stretch, compress, and hold up to repeated cycles without tearing.

Available in clear and black. Other pigments available per request.
Supports resolutions of 100 microns.

RECOMMENDED FOR:

Wearables and consumer goods prototyping
Medical models and devices
Compliant features for robotics
Special effects props and models

NOT SUITABLE FOR:

Parts requiring high surface detail
Parts that need to hold a particular structure or shape
Parts requiring high dimensional accuracy

FLEXIBLE RESIN

An 80A Shore durometer material for more rigid flexible parts with a matte-black soft-touch finish. Choose Flexible Resin to create ergonomic features as part of larger assemblies.

Available in dark grey.
Supports resolutions of 100 and 50 microns.

RECOMMENDED FOR:

Cushioning and damping
Functional prototypes
Ergonomic prototyping: handles, grips
Simulating soft-touch materials
Adding soft overmolds to multi-material assemblies
Packaging
Stamps

NOT SUITABLE FOR:

Simulating very high elongation materials (rubber band)
Very fine features or thin walls

HIGH TEMP RESIN

High Temp Resin offers a heat deflection temperature (HDT) of 238 °C @ 0.45 MPa, the highest among Formlabs resins. Use it to print detailed, precise prototypes with high temperature resistance.

Available in transparent white.
Supports resolutions of 100, 50, and 25 microns.

RECOMMENDED FOR

Hot air, gas, and fluid flow
Heat resistant mounts, housings, and fixtures
Low volume injection molds and inserts
Vulcanization

NOT RECOMMENDED FOR

Production injection molding
Parts that will be under load
Snap-fits and/or flexible parts

SLS PROCESS

Laser sintering of powdered thermoplastic.

Materials: Services

NYLON (PA12)

Features good strength properties, resistance to moderate chemicals and high fatigue resistance. These characteristics make it a good choice for applications involving snap-fit closures, tools with press-fit inserts, components subject to high vibration and part requiring thread inserts.

Matte Charcoal Grey
100µm Layer Height

NYLON (PA11)

Coming Soon (Q4 2021)

Features excellent elasticity, resistance to moderate chemicals and high elongation at break. These characteristics make it a good choice for applications involving spring like features, living hinges and tools requiring high impact resistance.

Matte Charcoal Grey
100µm Layer Height
